Uni-T Thermal Imaging Camera 30 to 45 °C 160 x 120 pixels 9Hz UTi165K

Uni-T Thermal Imaging Camera
Product Code: HB-3624
Brand: UNI-T
Warranty: 7 Days Warranty
Availability: In Stock
Rs. 79,999
You save Rs. 20,000 (20% Off)

Features :

  • Durable and user-friendly
  • IR resolution: 160×120
  • 8” TFT display screen (320×240 Pixels)
  • Temperature measurement range: 30℃ to 45℃
  • Auto alarm for high temperature
  • Image modess: Thermal,Visual image,Fusion
  • Color palattes: 7(Ironbow, Rainbow, White hot, Black hot, Red hot, Lava, Rainbow HC)
  • PC software analysis
  • Real-time image projection
  • RIO
  • LED flashlight
  • Rechargeable Li-ion battery
  • 1/4” tripod mounting hole

Product Specifications of UTi165K

Technical Data
IR resolution (Pixels)160×120
Display2.8”TFT LCD (320×240)
Field of view(FOV)56°×42°
Thermal sensitivity(NETD)≤50mk
Spatial resolution(IFOV)6.1mrad
Frame rate≤9Hz
Spectral range8~14µm
FocusFocus Free
Temperature measurement range30℃~45℃ (86℉-113℉)
Accuracy±0.5° (@25˚C ambient temperature)
Emissivity0.01~1.00 adjustable (0.95 default)
Functions
Color palettes7
(Ironbow, Rainbow, White hot, Black hot, Red hot, Lava, Rainbow HC)
Image modesThermal,Visual Image,Fusion
On screen analyzer3 Points
Digital camera resolution640×480
Hi/Lo temperature alarmIcon,LED flashlight
Software analysisPC
General Characteristics
BatteryFixed Li-ion battery (3.6V 5000mAh)
Battery operation time ≥ 6 hours
USBType-C
Storage32G Micro SD card
Image/Video storage formatBMP
CertificatesCE,FCC,RoHS
Product net weight910g
Product size236mm×75.5mm×86mm
Packing Details
Standard accessoriesType-C USB cable, Micro SD card, English manual
Standard individual packingGift box
Standard Qty per carton10pcs
Standard carton size500mm×315mm×295mm
Standard carton G.W.2.2kg
